What is the Wilson Tool International tooling system?
Wilson Tool International supplies tooling under the WT style (20 mm), American, European 60 / 90 mm, Z1 / Z2, UBP. If your machine is already equipped with this system, replacement tools are specified to match it — the tang geometry, the working height and the retention method all have to agree, not just the nominal size.
| Wilson Tool International | |
|---|---|
| Type | Independent tooling brand |
| Origin | United States |
| System | WT style (20 mm), American, European 60 / 90 mm, Z1 / Z2, UBP |
| Catalogue number format | E00000000 (8 digits) / 00000 (5 digits) / 0DH00 (clamping) |
| Replacement tooling | Aftermarket equivalent made to the system |
How are Wilson Tool International catalogue numbers structured?
Wilson publishes different number formats per catalogue. Wila style tooling uses an eight digit number such as E91180010, with length variants written as a suffix, for example E91180010 - 550X. American style tooling uses a five digit number such as 50326, where a trailing G denotes a straight groove variant. Clamping products use a compact form such as 6DH45. Wilson publishes an official part number building key for its clamping range, and that key is the authoritative decoding source for those products.
- A catalogue number identifies the profile; it does not replace measuring the tool.
- Worn or reground tools keep their number but lose working height.
- Where a brand publishes an official decoding key, that key is authoritative — not third-party guesses at what the digits mean.
Wilson catalogue number samples (Wila style)
The numbers below are real catalogue numbers taken from the Wilson Wila style catalogue. Length variants are written as a suffix, for example a 550X sectionalised set.
| Catalogue number | Angle | Source page |
|---|---|---|
| E90228010 | 28° | 7 |
| E91228010 | 28° | 9 |
| E92228010 | 28° | 10 |
| E92428030 | 28° | 11 |
| E93228010 | 28° | 13 |
| E95030016 | 30° | 19 |
| E95030020 | 30° | 20 |
| E95030024 | 30° | 21 |
| E95130008 | 30° | 16 |
| E95130010 | 30° | 17 |
| E95130012 | 30° | 18 |
| E96030016 | 30° | 19 |
| E96030020 | 30° | 20 |
| E96030024 | 30° | 21 |
| E96130006 | 30° | 15 |
| E96130008 | 30° | 16 |
| E96130010 | 30° | 17 |
| E96130012 | 30° | 18 |
Wilson to Wila cross reference
Wilson's Wila style catalogue prints its own number alongside the Wila number, which gives a published cross reference for that system.
What should I send to identify a replacement?
If your catalogue number is not listed, send us the number together with a photograph of the tool and a ruler shot of the tang. We will confirm the system, angle, radius, height and segment length before you order.
- The catalogue number stamped or laser marked on the tool.
- The angle and tip radius, if legible.
- The working height from shoulder to tip.
- The total length and any segment combination.
- A photograph of the tool and of the tang with a ruler in shot.
